- Optical System
- Light source: 7PCS (OSRAM OSTAR) 15W 4in1 RGBW LED
- LED lifespan: 50,000 hours
- Zoom range: 10° - 50°
- Dynamic Effects
- Pixel control: 7 pixel (each LED as a pixel), individually controllable
- Petal-like mini beam effects
- Pixel patterning macro effects
- Built-in running programs
- Built-in color and graphic effect macros
- 0-100% electronic dimmer
- Shutter: 1-25 times/s strobe, variable/random strobe and dimming pulse effect
- Control and Program
- LCD display
- Protocol: DMX512, master-slave, sound control, auto
- Control channels: 27/55 CH
- Pan/Tilt resolution: 16 bit smooth scanning
- Housing
- Aluminium structure with die-cast plastic cover
- Movement
- Pan movement: 540°
- Tilt movement: 240°
- Scanning position memory
- Automatic Pan/Tilt position correction
- Electrical Specification and Connections
- Power supply: Electronic ballasts and switching
- Input voltage: AC 100-240 V, 50/60 Hz
- Power consumption: 120 W
- Power connector in/out: Powercon
- Data connector in/out: 3-pin XLR
- 1PC 1/4 turn fastening Omega clamp
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP20
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 300*220*400 mm (11.8*8.7*15.7 inch)
- Carton: 380*340*420 mm (15*13.4*16.5 inch)
- Net weight: 8 kg (17.6 lbs)
- Gross weight: 9 kg (19.8 lbs)
- Packing List
- MINIEYE 715
- User manual
- Power cable
- 3-pin XLR connectors
- Optional Accessories
- Flight case: 2pcs in 1
- Clamp
- Safety rope
- DMX wire
